Seagate
16384 GB
SATA 6Gb/s
pro podnikové a serverové použití
7200 ot./min
Exos X16
256 MB
670 g
261 MB/s
249 MB/s
Formát:3.5"; Rozhraní:interní Serial ATA III; Kapacita pevného disku (v GB):16 000; Rychlost otáček (v RPM):7 200; Typ disku:HDD; Velikost bufferu (v MB):256
Scalable. Responsive. Innovative. Exos X16
Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate X class, the Exos X16 enterprise hard drives are the highest-capa...
Formát:3.5"; Rozhraní:interní Serial ATA III; Kapacita pevného disku (v GB):16 000; Rychlost otáček (v RPM):7 200; Typ disku:HDD; Velikost bufferu (v MB):256
Scalable. Responsive. Innovative. Exos X16
Seagate manufactures hard drives that specifically address the needs of the hyperscale storage market. As the flagship of the Seagate X class, the Exos X16 enterprise hard drives are the highest-capacity hard drives in the fleet.
Best-Fit Applications
- Hyperscale applications/cloud data centres
- Massive scale-out data centres
- Big data applications
- High-capacity density RAID storage
- Mainstream enterprise external storage arrays
- Distributed file systems, including Hadoop and Ceph
- Enterprise backup and restore — D2D, virtual tape
- Centralised surveillance
TECHNICAL SPECIFICATIONS
Specifications
SATA 6 Gb/s
Capacity
16TB
™ 1
Standard Model FastFormat (512e/4Kn)
ST16000NM001G
1,2
SED Model FastFormat (512e/4Kn)
ST16000NM003G
1,2
SED-FIPS FastFormat (512e/4Kn)
—
Helium Sealed-Drive Design
Yes
Protection Information (T10 DIF)
—
SuperParity
Yes
Low Halogen
Yes
™
PowerChoice Idle Power Technology
Yes
™
PowerBalance Power/Performance Technology
Yes
3 Hot-Plug Support
Yes
Cache, Multi-segmented (MB)
256
Organic Solderability Preservative
Yes
RSA 2048 Firmware Verification (SD&D)
Yes
Mean Time Between Failures (MTBF, hours)
2,500,000
Reliability Rating @ Full 24×7 Operation (AFR)
0.35%
Non-recoverable Read Errors per Bits Read
1 sector per 10E15
Power-On Hours per Year (24×7)
8,760
512e Sector Size (Bytes per Sector)
512
4Kn Sector Size (Bytes per Sector)
4,096
Limited Warranty (years)
5
Spindle Speed (RPM)
7,200 RPM
Interface Access Speed (Gb/s)
6.0, 3.0
Max. Sustained Transfer Rate OD (MB/s, MiB/s)
261, 249
Random Read/Write 4K QD16 WCD (IOPS)
170/440
Average Latency (ms)
4.16
Interface Ports
Single
Rotation Vibration @ 20-1500 Hz (rad/sec2)
12.5
Idle A (W) Average
5 W
Max Operating, Random Read/Write 4K/16Q (W)
10.0, 6.3
Power Supply Requirements
+12 V and +5 V
Temperature, Operating (°C)
5°C – 60°C
Vibration, Non-operating: 2 to 500 Hz (Grms)
2.27
Shock, Operating 2 ms (Read/Write) (Gs)
50
Shock, Non-operating 2 ms (GS)
200
4 Height (mm/in, max)
26.11 mm/1.028 in
4 Width (mm/in, max)
101.85 mm/4.01 in
4 Depth (mm/in, max)
147 mm/5.787 in
Weight (lb/g)
670 g/1.477 lb
Carton Unit Quantity
20
Cartons per Pallet / Cartons per Layer
40/8
1 FastFormat models ship in 512e format state. When switching from 512e to 4Kn by executing the FastFormat routine, all data on the drive will be deleted. Note that data must be aligned to 4K sectors to see improved performance in 4Kn fomat.
2 Self-Encrypting Drives (SED) and FIPS 140-2 Validated drives available through franchised authorised distributors. May require TCG-compliant host or controller support.
3 Supports Hotplug operation per Serial ATA Revision 3.2 specification
4 These base deck dimensions conform to the Small Form Factor Standard (SFF-8301) found at www.sffcommittee.org. For connector-related dimensions, see SFF-8323.
