Ortofon Cadenza Bronze
Ortofon
Technical SpecificationsOutput voltage at 1000 Hz, 5cm/sec. 400 ?VChannel balance at 1 kHz < 1 dBChannel separation at 1 kHz > 24 dBChannel separation at 15 kHz > 20 dBFrequency range at - 3dB 20 - 55 kHzFrequency response 20 Hz - 20 kHz +1,5Tracking ability at 315Hz at recommended tracking force *) 80 µmCompliance, dynamic, lateral 12 µm/mNStylus type Nude Ortofon replicant,, conical aluminiumSty...
Technical SpecificationsOutput voltage at 1000 Hz, 5cm/sec. 400 ?VChannel balance at 1 kHz < 1 dBChannel separation at 1 kHz > 24 dBChannel separation at 15 kHz > 20 dBFrequency range at - 3dB 20 - 55 kHzFrequency response 20 Hz - 20 kHz +1,5Tracking ability at 315Hz at recommended tracking force *) 80 µmCompliance, dynamic, lateral 12 µm/mNStylus type Nude Ortofon replicant,, conical aluminiumStylus tip radius r/R 5/100 µmTracking force range 2,2-2,7 g (22-27 mN)Tracking force, recommended 2,5 g (25 mN)Tracking angle 23°Internal impedance, DC resistance 5 OhmRecommended load impedance 50-200 OhmCartridge body material Stainless steel / AluminiumCartridge colour Bronze/BlackCartridge weight 10,7 gram
