Noctua NF-A14 industrialPPC-3000 PWM

Noctua 140 x 140 mm Self-stabilising Oil-pressure Bearing (SSO2) 158 CFM automatická 4pin bez podsvícení

Noctua NF-A14 iPPC-3000 PWM 140x140x25 mm, 4-pin
Conceived for industrial heavy duty applications that require enhanced cooling performance and advanced ingress protection, the NF-A14 industrialPPC (Protected Performance Cooling) is a ruggedised high-speed version of the award-winning retail model. Thanks to the outstanding aerodynamic efficiency of the NF-A14 design and the use of a novel three-phase motor, the industrialPPC version provides superior airflow and pressure capacity while keeping noise levels and power consumption moderate as against comparable high-speed fans. While its fibre-glass reinforced polyamide construction and certified water and dust protection make the NF-A14 industrialPPC suitable for operation in challenging environments, the renowned SSO2 bearing technology guarantees an MTBF of over 150.000hrs. Topped off with Noctua’s trusted reliability and 6 years manufacturer’s warranty, the NF-A14 industrialPPC is an ideal choice for highly demanding applications that require superior flow rates and ultimate dependability.
Specifications:
Size: 140x140x25 mm
Connector: 4-pin PWM
Bearing: SSO2
Blade Geometry: A series with Flow Acceleration Channels
Frame Technology: AAO
Rotational Speed (+/- 10%): 3000 RPM
Min. Rotational Speed (PWM, +/-20%): 800 RPM
Airflow: 269,3 m^(3)/h
Acoustical Noise: 41,3 dB(A)
Static Pressure: 10,52 mm H2O
Max. Input Power: 6,6 W
Max. Input Current: 0,55 A
Voltage: 12 V
MTBF: -gt; 150.000 h
Scope of Delivery:
• Fan
• 4 Fan Screws
Ingress Protection: IP52
Material: Fibre-glass reinforced polyamide
Motor type: Three-phase
