Cisco CBS110-5T-D

Cisco switch CBS110-5T-D
Switche Cisco Business řady 110 jsou cenově dostupné základní switche typu plug-and-play, které poskytují přepínání gigabitového Ethernetu s klíčovými funkcemi, jako je napájení přes Ethernet (PoE), energetická účinnost a prioritizace provozu pro rychlou a spolehlivou síť malých firem.
Stránky produktu: CBS110-5T-D
Quick start guide: Quick start guide
Switching capacity and forwarding rate
Capacity in millions of packets per second (mpps) (64-byte packets) 7,4 mpps
Switching capacity in gigabits per second (Gbps) 10 Gbps
General
Head-of-Line (HOL) blocking HOL blocking prevention
MAC table 2K addresses
Jumbo frame 9216 bytes
Quality of Service (QoS) 802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR)
Loop detection Helps discover loops in the network to avoid broadcast storms
Cable diagnostics Quickly identify and troubleshoot network cable faults and/or shorts
Media-dependent interface Automatic Media Dependent Interface (MDI) and MDI crossover (MDI-X)
Standards IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet
Hardware
Total system ports 5 Gigabit Ethernet
RJ-45 ports 5 Gigabit Ethernet
Combo ports (RJ-45 + Small Form-factor Pluggable [SFP]) 0
LEDs Power, link/activity (cable diagnostics, loop detection), Gigabit, PoE*, Max PoE* - *if present
Cabling type Category 5e or better
Mounting options Desktop
Physical security lock Kensington lock slot
Packet Buffer 1 Mbit
Environmental
Unit dimensions (W x D x H) 110 x 75 x 30 mm (4.33 x 2.95 x 1.18 in)
Unit weight
0.23 kg (0.52 lb)
Power 100 to 240V, 50 to 60 Hz, external, universal
Power consumption (worst case)
System power consumption 110V=2.74W
220V=2.69W
Heat dissipation (BTU/hr) 9,34
Green (power efficiency) Supports IEEE 802.3az on all copper Gigabit Ethernet ports
Compliance/certifications UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B*
*select models
Operating temperature 32° to 104°F (0° to 40°C)
Storage temperature –4° to 158°F (–20° to 70°C)
Operating humidity 10% to 90%, relative, noncondensing
Storage humidity 5% to 90%, relative, noncondensing
Acoustic noise and Mean Time Between Failures (MTBF)
Fan (number) Fanless
Acoustic noise N/A
MTBF at 25°C (hours) 4,243,002
Warranty Limited lifetime
Package contents Cisco Business 110 Series switch
Power cord or adapter
Quick start guide
Minimum requirements Devices supporting 802.3 Ethernet, 802.3u Fast Ethernet, or 802.3ab Gigabit Ethernet
Cat5e or better Ethernet cable
Network interface card for each computer
